ECO Other thicknesses
TECHNICAL DATA
DOWNLOAD
IT:FILETTO REF.EN:REF. THREADFR:Filet Ref.DE:Gewinde Ref.ES:Rosca Ref.CZ:Závit Ref.PL:Gwint Ref.
| Codice | A | B | C | D | E |
|---|---|---|---|---|---|
| AAM0035MAP ECO | 6.7 | 13.0 | 2.4 | 0.9 | 1.0 |
| AAM0069MAP ECO | 7.9 | 14.0 | 2.2 | 0.9 | 1.0 |
| AAM0102AP ECO | 7.9 | 13.7 | 2.3 | 0.9 | 1.0 |
| AAM0073 ECO | 8.0 | 11.0 | 2.1 | 0.9 | 1.0 |
| AAM0038MAP ECO | 8.7 | 15.0 | 2.2 | 0.9 | 1.0 |
| AAM0103AP ECO | 8.7 | 14.9 | 2.3 | 0.9 | 1.0 |
| AAM0030 ECO | 11.0 | 14.0 | 0.8 | 0.9 | 1.0 |
| AAM0070MAP ECO | 11.4 | 18.0 | 2.6 | 0.9 | 1.0 |
| AAM0104AP ECO | 11.4 | 18.0 | 2.3 | 0.9 | 1.0 |
| AAM0031 ECO | 14.0 | 18.0 | 0.8 | 0.9 | 1.0 |
| AAM0037MAP ECO | 14.9 | 21.7 | 2.5 | 0.9 | 1.0 |
| AAM0105AP ECO | 14.9 | 21.7 | 2.8 | 0.9 | 1.0 |
| AAM0080 ECO | 16.9 | 25.5 | 2.9 | 0.9 | 1.0 |
| AAM0043MAP ECO | 17.9 | 29.9 | 2.8 | 0.9 | 1.0 |
| AAM0106AP ECO | 17.9 | 26.9 | 2.8 | 0.9 | 1.0 |
| AAM0107AP ECO | 17.9 | 26.9 | 2.8 | 0.9 | 1.0 |
| AAM0032 ECO | 20.0 | 24.0 | 0.8 | 0.9 | 1.0 |
| AAM0045 ECO | 20.5 | 28.0 | 0.6 | 0.9 | 1.0 |
| AAM0071MAP ECO | 21.8 | 30.0 | 3.2 | 0.9 | 1.0 |
| AAM0046 ECO | 23.5 | 34.0 | 0.6 | 0.9 | 1.0 |
| AAM0033 ECO | 25.0 | 31.0 | 0.8 | 0.9 | 1.0 |
