ECO Caps female push-on
TECHNICAL DATA
DOWNLOAD
IT:FILETTO GASEN:GAS THREADFR:Filetage pour gazDE:Gas-GewindeES:Rosca GasCZ:Plynové vláknoPL:Gwint gazowy
| Codice | A | B |
|---|---|---|
| TSTR 1/8 G ECO | 12.0 | 13.0 |
| TSTR 1/4 G ECO | 15.0 | 13.0 |
| TSTR 3/8 G ECO | 18.5 | 13.5 |
| TSTR 1/2 G ECO | 22.5 | 16.5 |
| TSTR 3/4 G ECO | 29.5 | 22.5 |
| TSTR 1 G ECO | 36.5 | 21.5 |
| TSTR 1-1/4 G ECO | 45.0 | 23.5 |
| TSTR 1-1/2 G ECO | 50.5 | 28.5 |
| TSTR 2 G ECO | 62.5 | 27.5 |
IT:FILETTO METRICAEN:METRIC THREADFR:Filetage métriqueDE:Metrisches GewindeES:Rosca métricaCZ:Metrický závitPL:Gwint metryczny
| Codice | A | B |
|---|---|---|
| TSTR 10 ECO | 12.0 | 13.0 |
| TSTR 12 ECO | 15.0 | 13.0 |
| TSTR 14 ECO | 16.0 | 14.5 |
| TSTR 16 ECO | 18.5 | 13.5 |
| TSTR 22 ECO | 25.0 | 20.5 |
| TSTR 26 ECO | 29.5 | 22.5 |
| TSTR 30 ECO | 33.0 | 17.0 |
| TSTR 42 ECO | 45.0 | 23.5 |
IT:FILETTO UNFEN:UNF THREADFR:Filet UnfDE:Unf-GewindeES:Rosca UnfCZ:Závit UnfPL:Gwint Unf
| Codice | A | B |
|---|---|---|
| TSTR 7/16 U ECO | 13.5 | 13.5 |
| TSTR 1/2 U ECO | 15.0 | 13.5 |
| TSTR 9/16 U ECO | 16.0 | 14.5 |
| TSTR 5/8 U ECO | 20.5 | 19.0 |
| TSTR 3/4 U ECO | 21.0 | 17.0 |
| TSTR 7/8 U ECO | 25.0 | 20.5 |
| TSTR 1-1/16 U ECO | 29.5 | 22.5 |
| TSTR 1-3/16 U ECO | 33.0 | 17.0 |
| TSTR 1-5/16 U ECO | 36.0 | 21.5 |
| TSTR 1-5/8 U ECO | 45.0 | 23.5 |
